What to Send a Moulder When You Ask for a Quote

A moulding quote is only as good as the information behind it.

Send a drawing and a rough quantity and you will get a number back, but it will carry assumptions. Those assumptions surface later as revised pricing, extended lead times, or a tool that does not do quite what was expected.

Sending a complete package up front takes an hour or two and removes most of that.

3D CAD, not just a drawing

A 2D drawing tells a moulder what the part looks like. A 3D model tells them how it will be made.

Native CAD is preferred where possible. Where it is not, a neutral format such as STEP or IGES works, though some feature information is lost in translation.

The model is what allows a toolmaker to assess the parting line, where ejection can act, how many cavities are viable, and whether the geometry is going to need side actions. Those decisions drive tooling cost more than almost anything else, and none of them can be made confidently from a flat drawing.

If a 2D drawing exists alongside the model, send both. The drawing carries the tolerances and notes that the model does not.

Estimated annual usage

Volume determines the entire approach.

A few thousand parts a year and a few hundred thousand a year are different projects. They point to different tool materials, different cavitation, different levels of automation and different unit economics. A tool built for one is the wrong tool for the other.

An honest range is more useful than a precise-sounding guess. If the figure could be 20,000 or could be 200,000 depending on how a launch goes, say that. A moulder can then quote a tool that has a route to higher cavitation later, rather than one that has to be replaced.

Expected product lifespan matters alongside it. A part running for ten years justifies a different tool specification to one running for two.

Tolerances, and which ones actually matter

This is where quotes most often go astray.

Applying a tight general tolerance across an entire drawing is common and expensive. Moulded plastic shrinks as it cools, and the amount depends on the material, the wall section and the direction of flow. Holding a tight tolerance is achievable but it constrains tool design, cycle time and sometimes material choice.

What helps is identifying which dimensions are critical and why. A bore that takes a bearing, a face that seals, a snap fit that has to engage. Those need to be held. The rest can usually sit at a standard tolerance without affecting anything.

Marking up a drawing to distinguish the two is one of the more useful things a customer can do, and it often reduces both tooling cost and unit price.

Material, or the requirements behind it

If the material is already specified, send the grade rather than the family. Polypropylene covers an enormous range and the differences between grades are not trivial.

If it is not yet specified, describe what the part has to survive. Operating temperature range, chemical exposure, UV, load, impact, whether it needs to be food contact or flame retardant, and any regulatory standard it has to meet.

A moulder can work from requirements. Guidance on how material choice affects cost is set out in the piece on the main drivers of polymer prices.

Finish, colour and anything applied after moulding

Surface finish affects tool cost directly. A textured finish, a polished finish and a standard finish are three different amounts of toolmaking work.

Colour needs stating, along with whether it is matched to a reference. Where a specific match is required, send the reference rather than a description.

Anything happening after the part leaves the tool should be included too. Inserts, pad printing, ultrasonic welding, assembly with other components, or packing in a particular format. These often make more difference to unit price than the moulding itself, and they are frequently left out of the initial enquiry.

Commercial and practical detail

Target price, if there is one. It is not a weakness to state it. Knowing the target lets a moulder tell you early whether it is achievable, and if not, what would have to change.

Timing, both for tooling and for first production parts.

Whether the tool is being funded outright, amortised across parts, or transferred from an existing supplier. Existing tooling changes the conversation entirely.

Delivery expectations, call-off pattern and any stock holding requirement.

Design responsibility stays with you

Worth being clear on this, because it shapes what the quote covers.

Cameron-Price provides the manufacturing input. The design of the part, and its fitness for the application it is going into, remains with the customer. What a moulder will do is flag where a geometry is going to cause difficulty in tooling, moulding, assembly or dispatch, and suggest changes that would make it more manufacturable.

That feedback is more useful early. Once a design is fixed and signed off elsewhere, the options narrow considerably. The design and development capability page sets out where that input fits.

Sending an enquiry

A complete package is model, drawing, volumes, critical tolerances, material or requirements, finish and colour, post-moulding operations, and timing.

With that, a quote comes back faster and holds its shape. Without it, the first number is provisional whether it says so or not.

To discuss a project, get in touch through the contact page.
